FTTH Cable Production: How the Manufacturing Process Works
Did you know: in excess of 70% of U.S. broadband rollouts now depend on fiber networks that demand high-precision manufacturing to hit performance targets.
Shanghai Weiye OFC Equipment runs full-cycle compact fiber unit manufacturing, from choosing brand fibers like Fujikura or Corning® SMF-28e to comprehensive test documentation that deliver 100% QA.
Our drop designs suit overhead, underground, and direct-buried installation, with LSZH, PVC, and PE jacket options and configurations from 1 to 4 cores. We provide OS1/OS2 and multimode OM2–OM4 grades plus G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and logo printing.
Automation and high-precision equipment keep line speed steady and keep repeatability high. Typical lead times run four to five days for orders under 100 km and 7–10 days for < 500 km, with an min. order of 1 km and warranty for free replacement on quality issues.
Keep reading to understand how materials, testing, and support work together to reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment provides full manufacturing with lab validation for U.S. deployments.
- Multiple jacket choices and fiber grades support different install environments.
- Automated lines and machines ensure stable quality and reliable optical performance.
- Fast lead times, low MOQ, and recognized brand fibers keep procurement predictable.
- Comprehensive test reports and warranty back product reliability and documentation needs.
Specialized FTTH Manufacturing by Shanghai Weiye OFC Equipment
When project timelines and performance matter, Shanghai Weiye OFC Equipment delivers tailored drop solutions with full test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment combines purpose-built equipment with stringent material control. We offer custom builds and services for single-family and MDU rollouts. Every order comes with full QA coverage and full test reports.
Our lab conducts high heat, salt-fog, and vibration tests to verify durability. Jacket options include LSZH, PVC, and PE. Designs offer flat bow-type and self-supporting styles and support brand fibers such as Fujikura® and Corning SMF-28e.
- Controlled production lines and in-process checks for auditable shipments.
- Technical support for specs, trials, and ramp to volume.
- Modern fixtures and calibration reduce variability so every cable meets operator standards.
FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, pairing brand fiber choices with strict test routines.
Optical fiber selection and brand options
We match FTTH cable production line to bend radius, loss, and install environment. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura® and Corning SMF-28e are offered to satisfy sourcing standards.
Strength member integration
Strength members use dielectric FRP or metallic steel wire. FRP is preferred where non-conductive runs are required. Steel wire provides tensile strength for longer aerial spans and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for indoor flame safety, PVC for flexibility, and PE for outdoor UV and moisture resistance. Tight process control of extruder temperature and capstan speed stabilizes line speed and critical dimensions.
| Component | FRP | Metallic Steel |
|---|---|---|
| Primary use | Non-conductive runs | High-tension aerial runs |
| Advantage | Lightweight, inert | Very high tensile strength |
| Installation note | Simple terminations | Requires grounding |
Testing & Verification
Inline geometry and concentricity checks operate in-line. Final optical tests confirm attenuation and return loss. Each order includes a full test report and lab results from high-temperature, salt fog, and vibration trials to confirm handling for drop terminations and field use.
Typical lead times are under 100 km in 4–5 days and 7–10 days for < 500 km. Material lot records and first-article approvals provide traceability and compliance for U.S. projects.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a focused portfolio of FTTH drop designs that suit both tight indoor routes and exposed aerial spans. Each option combines tested materials with field-termination geometry and consistent optical performance.
The flat bow-type drop minimizes footprint for risers and conduit. It reduces bend loss for simple routing in hallways and MDUs.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs include a support messenger to handle tension. Choose FRP (dielectric) for electrical isolation or steel messenger when bonding and extra tensile strength are required.
Layouts & Strength Members
We offer both dielectric and metallic strength member configurations to match safety and EMI rules. Center loose tube and unitube flat types balance crush resistance and compact fiber unit for quick termination.
Jackets for Indoor/Outdoor
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor durability. Each series is qualified for mechanical/optical performance before shipment.
| Type | Application | Strength element | Jacket |
|---|---|---|---|
| Flat bow-type | Indoor risers, MDUs | Dielectric FRP | LSZH |
| Self-supporting (aerial) | Aerial spans | FRP/Steel | PE |
| Center loose tube | Higher fiber counts | Dielectric FRP | LSZH or PE |
| Unitube flat | Low count, quick strip | FRP/Steel | LSZH or PE |
Production Assets for Speed and Quality
Automation with sensor feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for patch cord prep.
Our production line uses automated machines that cut and strip drop patch cords to increase output and cut labor variability.
The CLX-BPO2 automated stripper runs under PLC and photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Automated cutting and stripping for drop cable patch cords
The equipment strips LSZH and PVC jackets and trims FRP/steel members to precise stub lengths. Pneumatic cylinder actuators deliver fast, repeatable motion and minimize downtime.
Closed-Loop Control for Repeatability
PLC logic + photoelectric sensors give exact positioning and feedback control. Inline checks feed control charts so operators can adjust drifts before out-of-control conditions occur.
| Item | Spec | Result |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | High throughput |
| Drive | Pneumatic cylinders | High speed and reliability |
| Material handling | LSZH/PVC; FRP/steel | Clean, accurate preps |
| Control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Automated waste ejection and ergonomic loading maintain clean workcells.
- PCPs document calibration and key parameters.
- Integrated assets and trained operators help meet FTTH volume goals without sacrificing accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize prep quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC and photoelectric control deliver exact detection and repeatable actuation. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Line Speed
Typical operation speed is 1.5s per cycle. This enables steady throughput under normal production conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable strip length from 17.5–35.0 mm. Reserved strength member stubs are adjustable from 7.0–11.0 mm to match common termination hardware.
FRP & Steel Member Handling
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Custom tooling are available for nonstandard sizes to preserve precision.
- Automatic waste ejection and sensor start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass ease integration into workcells.
- Cylinder-driven motion and closed-loop control boost reliability and lower maintenance interruptions.
| Specification | Rating | Why it matters |
|---|---|---|
| Cycle time | ≈1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5–35.0 mm | Fits common connector processes |
| Reserved stub (B) | 7.0–11.0 mm | Supports termination strength |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures every order to meet your network requirements and simplify field rollout. We pair concise options with predictable manufacturing windows so your teams get install-ready reels.
Choose 1–4 core designs with SM or MM fiber. Options include OS1/OS2 plus OM2–OM4 along with G.652D and G.657 variants to align with optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tags.
Jackets, Legends & Branding
Select LSZH/PVC/PE jackets to suit route and safety requirements. Custom legends/logos support inventory and warranty tracking.
Length options, packaging, and special structures
Standard put-ups are 1 km, 2 km, and 4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to fit span and isolation requirements.
| Option | Common choice | Advantage |
|---|---|---|
| Length | 1 / 2 / 4 km | Simpler staging and reels |
| Sheath | LSZH, PE, PVC | Indoor/outdoor compatibility |
| Structure | Bow-type / Self-supporting | Routing and span flexibility |
As a manufacturer, Shanghai Weiye schedules runs to your plan and provides docs that lists final specifications for straightforward QA on site.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
High-temperature, salt spray, and vibration laboratory testing
Our lab conducts elevated-temperature exposure, salt fog corrosion, and mechanical vibration to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
Per-Reel 100% Reports
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Audit Trail and Compliance
Lot/batch records tie test data to reels and serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to accelerate approvals and receiving inspection.
- Line checks and final inspection reduce field failures and lower warranty events.
- Quality packages include specifications confirmation and formatted data for rapid review.
- Ongoing trend analysis drive preventive maintenance and improve long-term reliability.
| Test | Why | Outcome |
|---|---|---|
| High-temperature | Thermal stability | Validated heat endurance |
| Salt-fog | Corrosion resistance | Qualified for outdoor use |
| Vibration | Resistance to vibration | Improved field reliability |
FTTH Drop Cable Pricing & Cost Drivers
Budget planning for a drop begins with fiber/jacket selection and is shaped by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, reel length, and structural design.
Materials, Grade, Jacket & Structure
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting structures and steel strength elements increase material/labor. Custom sheath colors/logos/legends add setup and impact pricing on small runs.
Length/Volume/Customization Impact
Longer put-ups and larger volumes lower unit cost. Short runs often include setup charges and higher unit prices.
- Changeovers and special cutters extend lead time and add to cost.
- Clear RFQs and line scheduling let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Driver | Price impact | Recommendation |
|---|---|---|
| Optical grade | Large | Balance spec vs. budget |
| Sheath material | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate runs to cut unit cost |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable schedules cut downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to keep deliveries on time.
The service team provides updates/tracking so installation teams can plan arrivals. For tight schedules, we hold contingency capacity to pull in critical-path orders.
MOQ and Rationale
The MOQ is one kilometer. This reflects line setup such as wire/die adjustments that use startup material and generate scrap.
We review your length and staging plans to select reels to reduce waste/handling. Batch releases can balance inventory holding with more frequent small-site deliveries.
Installation Scenarios & Readiness
On-site conditions determine whether a self-supporting span, duct pull, or direct-buried run is the right choice for a project.
Aerial vs Duct vs Direct-Buried
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with correct strength members to control sag and tension for long-term reliability.
Duct installations perform best with low-friction jackets and crush-resistant constructs so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance matters.
Direct-buried designs need correct burial depth per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor riser/plenum distribution and ONT termination
Indoor riser and plenum routes prefer LSZH to meet smoke/flame codes. Flat drop cable forms strip cleanly and present controlled stubs for fast ONT terminations.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning risk, and hardware compatibility. Standardized line prep shortens install time and reduces scrap.
| Scenario | Key feature | Installer note |
|---|---|---|
| Overhead | Self-supporting (steel/FRP) | Verify messenger hardware/tension |
| Underground duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct-buried | PE jacket, moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH with tight-bend support | Maintain bend radius at penetrations |
Our approach ensures a consistent install experience across indoor outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
End-to-end support and after-sales service
Our team coordinates tests, line schedules, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements capture through approved drawings and pilot builds. We deliver documentation templates and clear install notes so field crews work from the same plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full reports and traceability to support QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for expedites and urgent changes.
- Config control so shipped items match agreed specs consistently.
| Support area | What we do | Outcome |
|---|---|---|
| Tech/Eng | Specs + pilots | Fewer field issues |
| QA/Testing | Lab + 100% reports | Full traceability |
| After-sales | Fast replace + RCA | Lower downtime |
Conclusion
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We deliver customized FTTH drop solutions that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented lab trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2 prep assets, cuts variability and shortens turnaround. Our equipment and machines standardize strip and stub lengths so installers get consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance performance and cost to maximize service life. Dedicated support covers scheduling/logistics/after-sales so your deployment stays on plan.
Contact Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
